Dual chamber H-cell membrane electrochemical reactor, capacity 50 to 500 ml, Not Sealed

Name: Dual chamber H-cell membrane electrochemical reactor, capacity 50 to 500 ml, Not Sealed - Labxsci
SKU: DCHME
Availability: InStock

SKU: DCHME

Price range: $175.00 through $369.00

$175.00 – $369.00

Capacity: No selection

More options

**Not Sealed H-Cell electrochemical reactor**

Include :

Volumes of a chamber in ml	Chamber Size (Diameter x Height in mm)	Electrodes Holes (Quantity x Diameter in mm)	Gas Holes (Quantity x Diameter in mm)	Diameter of Membrane channel in mm
50ml – 50 ml	Φ45 x40 mm	3 x Φ6.2 mm	4 x Φ3.1 mm	9 mm
100ml – 100 ml	Φ50 x 48 mm	3 x Φ6.2 mm	4 x Φ3.1 mm	15 mm
150ml – 150ml	Φ60 x 62 mm	3 x Φ6.2 mm	4 x Φ3.1 mm	15 mm
200ml – 200ml	Φ60 x 80mm	3 x Φ6.2 mm	4 x Φ3.1 mm	15 mm
250ml -250ml	Φ70 x 74 mm	3 x Φ6.2 mm	4 x Φ3.1 mm	15 mm
300ml -300ml	Φ70 x 88mm	3 x Φ6.2 mm	4 x Φ3.1 mm	15 mm
500ml -500ml	Φ90 x90 mm	3 x Φ6.2 mm	4 x Φ3.1 mm	15 mm

Additional information

Weight	N/A
Capacity: No selection	50 ml – 50 ml, 100 ml – 100 ml, 150 ml – 150 ml, 200 ml – 200 ml, 250 ml – 250 ml, 300 ml – 300 ml, 500 ml – 500 ml
